ABLIC Inc. today launched the “S-5701 B Series” surface mount TMR (Tunnel Magneto Resistance) sensor IC, a magnetic sensor IC with super-low current consumption, high magnetic sensitivity, long life and an operating current consumption of a mere 160nA.
The “S-5701 B Series” is a TMR sensor IC. However, unlike other MR sensor ICs such as Anisotropic Magneto Resistive (AMR) or Giant Magneto Resistive (GMR) sensor ICs, it features high sensitivity and super-low current consumption (160nA) making it an innovative product that solves the limitations of a conventional reed switch.
ABLIC has now added a new product, the “S-5701 B Series,” a TMR sensor IC in a “Small, Smart and Simple” product lineup that detects horizontal magnetic fields allowing us to further broaden our customer base by proposing it to customers who are seeking a replacement for the reed switch.
Major Features of the S-5701 B Series
The IC’s average current consumption is 160nA when using a power supply voltage of 3.3V. About 1/6th of the current consumption of a regular AMR IC
Operating voltage range: 1.7 to 5.5V, operation temperature range -40 to 125°C and satisfies a wide operating environment
Employs a super-thin TSOT-23-3S package
High magnetic sensitivity BOP = 1.0mT products available
Applications
•A reed switch replacement
Examples of products using this IC
•Window open/close sensors, electronic keys, smoke detectors
•Gas meters, water meters, smart meters
All registered trademarks and other trademarks belong to their respective owners. For more details, please visit ABLIC official site.
