ABLIC Inc. (ABLIC) that manufactures and sells semiconductor products today announced the launch of S-19251 Series, the world’s smallest*1 automotive LDO regulators.

The new S-19251 Series is the automotive LDO regulator featuring 150mA output current, 5.5V input voltage, 1.0 to 3.5V output voltage, 20μA current consumption, and the 105°C operating temperature. The package is the world’s smallest*1 HSNT-4(0808)B (0.8×0.8×0.41mm) that meets the strong demand for increasingly smaller packaging, yet achieves the low current consumption of 20μA. This IC is suitable for smaller automotive ECUs and typical applications include power supply for electrical applications of vehicle interior (meters, car bodies, headlights, ITS, accessories, car navigation systems, car audio systems, etc.).

Also the quality standard AEC-Q100 (Automotive Electronics Council reliability stress test) is in process, and PPAP (Automotive Production Parts Approval Process) approved by AIAG (Automotive Industry Action Group) is available upon request.

Features

World’s smallest*1 HSNT-4(0808)B package with high heat dissipation

Superior mounting made possible by leveraging outer leads

Automotive quality

Achieving both low current consumption of 20μA and high ripple rejection of 75dB

Specs

Output current: 150mA

Output voltage: 1.0V to 3.5V (0.05V Step)

Input voltage: 1.5V to 5.5V

Output voltage accuracy: ±2.5% (Tj = −40°C to +105°C)

Current consumption during operation: 20µA typ.

Ripple rejection: 75dB typ. (1.2V output product, f = 1.0 kHz)

Packages

HSNT-4(0808)B (The world’s smallest package for automotive use *1)

HSNT-4(1010)B

SOT-23-5

AEC-Q100 available

PPAP available

Applications

Meters, car bodies, headlights, ITS, accessories, car navigation systems, car audio systems, etc.

All registered trademarks and other trademarks belong to their respective owners. For more details, please visit ABLIC official site.
